Anti-theft Lock

Touch

Split Screen

Miracast

Remote Control

Customized
65inch :W1003*H2245*T790mm
Anti-theft Lock
Touch
Split Screen
Miracast
Remote Control
Customized
Display | 43″ | 49″ | 55″ | 65″ |
Screen Size | ||||
Panel Technology | IPS,M+(WRGB) | IPS.M+(WRGB) | IPS,M+(WRGB) | IPS,M+(WRGB) |
Back light type | WLED | WLED | WLED | WLED |
Aspect Ratio | 16:09 | 16:09 | 16:09 | 16:09 |
Native resolution | 1080*1920 | 1080*1920 | 1080*1920 | 2160*3840 |
Brightness | 300~350nits | 300~350nits | 300~350nits | 300~350nits |
contrast Ratio | 1200:1 | 1200:1 | 1200:1 | 1200:1 |
Dynamic CR | CR≥10 | CR≥10 | CR≥10 | CR≥10 |
Viewing Angle(H*V) | 178*178 | 178*178 | 178*178 | 178*178 |
Response time | 6ms | 6ms | 6ms | 8ms |
Surface Treatment(Haze. Quarter Wave plate) | (Haze 1%),Hard coating (3H) | (Haze 1%),Hard coating (3H) | (Haze 3%),Hard coating (2H) | (Haze 3%),Hard coating (2H) |
Life Time(Type) | 50,000 h – 60000 h | 50,000 h – 60000 h | 50,000 h – 60000 h | 50,000 h – 60000 h |
Operation Hours | 24h | 24h | 24h | 24h |
Orientation | Portrait & Landscape | Portrait & Landscape | Portrait & Landscape | Portrait & Landscape |
Input | HDMI, DP, VGA, USB*2 | HDMI, VGA, USB*2 | HDMI, VGA, USB*2 | HDMI,DP,VGA,AUDIO,USB |
Output | External Speaker Out(L/R) | External Speaker Out(L/R) | External Speaker Out(L/R) | External Speaker Out(L/R) |
External Control | RS232C In/Out, RJ45(LAN) In/Out | RJ45 | RJ45 | RJ45 |
Protection Glass | 4mm( Degree of Protection, Tempered) | 4mm( Degree of Protection, Tempered) | 4mm(IK 10, Degree of Protection, Tempered) | 4mm( Degree of Protection, Tempered) |
Bezel Color | Silver | Silver | Silver | Silver |
Bezel width | ||||
Monitor Dimension(WxHxD) | ||||
Weight(head) | ||||
Packing dimensions(WxHxD) | ||||
Packing weight(G.W) | ||||
NO system with HDMI input Optional Android or windows system | ||||
Operation Temperature | 0°C to 40 °C | 0°C to 40 °C | 0°C to 40 °C | 0°C to 40 °C |
Operation Humidity | .-10°C to 80 °C RH Non-condesing | .-10°C to 80 °C RH Non-condesing | .-10°C to 80 °C RH Non-condesing | .-10°C to 80 °C RH Non-condesing |
Power Supply | 100-240V~, 50/60Hz | 100-240V~, 50/60Hz | 100-240V~, 50/60Hz | 100-240V~, 50/60Hz |
Power Type | Built-In Power | Built-In Power | Built-In Power | Built-In Power |
Typ./Max. | 51W/73W | 50W/72W | 69W/99W | 68W/98W |
Safety | ||||
EMC | ||||
Super Sign | Yes(CMS, Control) | Yes(CMS, Control) | Yes(CMS, Control) | Yes(CMS, Control) |
Basic | Remote Controller, Manual(EIG, IG , OM), Regulation Book, Phone to RS232C Gender, HDMI Cable , POWER CABLE, Battery |
